Next meeting deliverables 01/02:

  • Data output research or Type-T thermocouples, as defined by IEC Standards 61515, Emily Aleman Garcia ,
  • Find other company to manufacture thermocouples multi-junction probe Emily Aleman Garcia
  • Preliminary Pressure Sensor choice and Data output format Asael Acosta
  • Preliminary Thermal Camera choice and Data output format Angelina Costa
  • Learn/Investigate/Make progress on Cindy's deliverables list and what we specifically have to deliver Israel Garcia


Update notes:

  • only one thermal camera on side profile
  • two pressure sensors on axial placements
  • New Thermocouple Choice from Emerson company

Deliverables:

  • Contacting companies for quote and data output specifications (specifically thermocouples)
  • Choose Camera? Pressure Sensor?
  • Update requirements in Nasa Systems Handbook format

    • Hi Angelina! Here's some things that are typical:

      • Interface Requirements: UART (RS-422/485/232) or Ethernet
      • Software Interface Control Document: details what is required to implement on Oligo's end in order to command your payload

      For the Software ICD, some typical contents include:
      • Data Exchange Architecture (e.g., what data does the payload expect? at what frequency does it communicate? does data need to be stored? any security needs? ACK/NACK?)
      • Physical Interface (more indepth info about the interface requirements)
      • Data Rate of Communication
      • Commanding Set (including data packet structure, state machines, failure modes, etc.)
      • Expected Telemetry
      • etc.
  • Learn/Investigate/Make progress on Cindy's list:


Thermocouple Standards:

  • No labels
